Details :
| Stock No | 1133-H119 |
| Machinetype | Machining Center - Horizontal |
| Make | TSUGAMI |
| Type | MA3 |
| Newin | 1985 |
| Control | CNC |
| Location | India - Rajkot |
| Country of origin | Japan |
| Term of delivery | |
| Quotation | Freiverladen LKW/Flat |
| Price | Auf Anfrage lkR |
Technical Details :
| x-travel | 300 mm |
| y-travel | 250 mm |
| z-travel | 400 mm |
| control | FANUC 6M |
| size of pallet | 300x300 mm |
| spindle taper | BT40 |
| spindle turning speed range | 4000 U/min |
| number of tools | 30 |
| total power requirement | 5.5 kW |
| weight of the machine ca. | 7 t |
| dimensions of the machine ca. | 6x3x3 m |
Other Details :
- Fanuc 6M; Pallet: 300x300mm
- X Travel 300 mm
- Y Travel 250 mm
- Z Travel 400 mm
- Pallet size: 300x300 mm
- Pallet changer 2 way mm
- Spindle taper (BT) 40 mm
- No. of tools in magazin 30 mm
- Spindle speed range 4000 mm
- Distance between spindle and table center 100 - 500 mm
- No. of pallet 10 mm/min
- Spindle motor 5.5 kW
